Wheel Backhoe Loader With Deep Excavation HT35-25 Introduction
The HIGHTOP HT35-25 Wheel Backhoe Loader is a multifunctional construction machine designed for professional users who need strong excavation performance, efficient loading capability, and flexible operation across different working environments. Combining a front loader bucket and rear backhoe system, this wheel backhoe loader integrates digging, loading, trenching, and material handling functions into one machine, helping contractors improve productivity and reduce the need for multiple types of equipment.
Unlike traditional single-purpose construction machinery, the HT35-25 provides both excavation and loading functions in one complete solution. The front bucket is suitable for soil, gravel, and construction material handling, while the rear excavator system is designed for deeper digging operations. With a maximum digging depth of 4100mm and optional telescopic digging arm reaching 5300mm, the machine can meet the requirements of foundation construction, drainage projects, pipeline installation, and other earthmoving applications.
Equipped with a four-wheel drive system, articulated hydraulic steering, and a powerful hydraulic system, the HT35-25 backhoe loader machine provides stable traction and smooth operation on different terrains. The wheel-type structure improves transportation efficiency between job sites, while the hydraulic control system helps operators achieve accurate digging and loading movements.
The HT35-25 is powered by a YUNNEI 4102 Turbo engine with a rated power of 76kW and features a 1.3m³ front loading bucket capacity, making it suitable for medium-scale construction projects that require higher working efficiency. For customers searching for a wheel backhoe loader for sale, 4x4 backhoe loader, or construction backhoe loader, HIGHTOP provides reliable equipment solutions with professional technical support, spare parts service, and customized options.
Wheel Backhoe Loader With Deep Excavation HT35-25 Parameters
| Model : HT35-25 | |||
| Overall Operating Weight | 6600KG | Engine | |
| Transport Dimension | Model | YUNNEI 4102 Turbo | |
| mm L*W*H | 7600x2100x3100 | Type: In Line Direct injection Four-Stroke Water Cooling | |
| Wheel base | 2250mm | Rated Power | 76KW |
| Min. Ground Clearance | 300mm | Rated Speed | 2400r/min |
| Bucket Capacity | 1.3m3 | Displacement | 4.4L |
| Breakout Force | 38KN | Steering System | |
| Loading Lifting Capacity | 2500KG | Steering Angle | +-360 |
| Bucket Dumping Height | 3500mm | Min. turning radius | 5018mm |
| Bucket Dumping Distance | 1022mm | Pressure of the system | 12Mpa |
| Digging Depth | 52mm | Axle | |
| Backhoe Capacity (Width) | 0.3m3(520mm) | Model | Wheel Hub Reducer |
| Max. Digging Depth | 4082mm | Final Reducer | Single Stage Final Reducer |
| Swing Angle of backhoe | 1900 | Transmission System | |
| Max. Pulling Force | 39KN | Torque Converter | |
| Gearbox | Model | YJ280 | |
| Type | Power Transmission | Type | Single- stage Three Elements |
| Gears | Two Gears Ahead Two Gears Astem | Cooling Method | Oil-cooling Pressure Circulation |
Wheel Backhoe Loader With Deep Excavation HT35-25 Images
Wheel Backhoe Loader With Deep Excavation HT35-25 Applications
The HT35-25 wheel backhoe loader is suitable for a wide range of professional applications. In construction projects, it can be used for foundation excavation, earthmoving, site preparation, and construction material loading. For infrastructure projects, the machine is suitable for road construction, drainage systems, pipeline installation, and municipal maintenance work. In agriculture, HT35-25 can support farmland improvement, irrigation channel construction, soil handling, and agricultural infrastructure development. It is also suitable for landscaping, property maintenance, and other projects requiring flexible excavation and loading equipment. With its deep excavation capability, strong loading performance, and four-wheel drive system, the HT35-25 provides an efficient solution for contractors and engineering companies.
HIGHTOP Service Support
HIGHTOP provides complete support services for HT35-25 wheel backhoe loader customers, including equipment consultation, configuration recommendations, spare parts supply, transportation assistance, and technical support.
Before purchasing, HIGHTOP engineers help customers select suitable configurations according to project requirements, working environment, and application conditions.
For distributors, contractors, and engineering companies, HIGHTOP supports bulk purchasing, OEM cooperation, and customized solutions.
After delivery, HIGHTOP provides operation guidance, maintenance recommendations, and technical assistance to help customers maintain stable equipment performance and reduce downtime.
Wheel Backhoe Loader With Deep Excavation HT35-25 Frequently Asked Questions
1. What is the HT35-25 wheel backhoe loader used for?
The HT35-25 is used for excavation, loading, trenching, road construction, agriculture projects, and municipal engineering applications.
2. What is the maximum digging depth of HT35-25?
The maximum digging depth is 4100mm, and the optional telescopic arm can increase digging depth up to 5300mm.
3. Does HT35-25 have four-wheel drive?
Yes. The HT35-25 uses a four-wheel drive system to improve traction and stability.
4. What is the loader bucket capacity?
The front loading bucket capacity is 1.3m³, suitable for efficient material handling.
5. Can HT35-25 be customized?
Yes. HIGHTOP provides optional configurations and customized solutions according to different market and project requirements.
