Mini Backhoe Loader With Versatile Operation HT20-28 Introduction
The HIGHTOP HT20-28 Mini Backhoe Loader is a multifunctional construction machine designed for users who need excavation, loading, and material handling capabilities in one compact piece of equipment. Combining a front loader bucket and rear digging system, this mini backhoe loader provides a practical solution for construction, agriculture, landscaping, and municipal engineering applications.
Compared with traditional single-purpose machines, the HT20-28 allows operators to complete multiple tasks with one machine. It can perform digging, trenching, loading, soil handling, and basic earthmoving operations, helping improve working efficiency while reducing the need for additional equipment.
The machine is equipped with an efficient engine and hydraulic working system, providing stable power output for daily operations. The hydraulic system ensures smooth movement of the loader arm and backhoe attachment, allowing operators to complete excavation and loading tasks with better control.
The compact structure and flexible steering system improve maneuverability, making the HT20-28 suitable for projects where working space is limited. It can operate effectively in construction sites, farms, roadsides, and other environments requiring flexible equipment movement.
The HT20-28 mini backhoe loader also supports different attachments, including buckets and drill rods, allowing users to adjust the machine according to different project requirements. This versatility makes it a reliable choice for customers looking for a small backhoe loader for sale, compact backhoe loader, or construction backhoe loader manufacturer.
HIGHTOP provides professional machinery solutions and supports customized equipment options for contractors, distributors, and engineering companies worldwide.
Mini Backhoe Loader With Versatile Operation HT20-28 Parameters
| Model:HT20-28 | |||
| DIMENSION | ENGINE | ||
| Overall size(mm) | 6200*1960*2800 | Engine Model | YUNNEI YN38GBZ |
| Wheel base(mm) | 2550 | Type | Four-Stroke |
| Wheel tread(mm) | 1580 | Rated Power(KW) | 76 |
| Min. Ground Clearance(mm) | 290 | Rated Rotary speed(r/min) | 2400 |
| PERFORMANCE PARAMETER | Cylinders - inner diameter | 3-90(4-90) | |
| Pressure of the system(MPa) | 18 | DRIVE SYSTEM | |
| Machine weight(Kg) | 5400 | Gearbox | Fixed shaft power shift |
| Max. speed(Km/h) | 28 | Optional Gears | Front 2 rear2 |
| Max Climb Capability(°) | 25 | Hydraulic torque converter | ZL29A |
| Min. turning radius(mm) | 4500 | EPS | |
| DIGGING PARAMETER | type | Articulated full hydraulic steering | |
| Max. Digging depth(mm) | 2600 | Steering angle(°) | 33 |
| Dumping Height(mm) | 2300 | BRIDGE | |
| Max. Digging Radius(mm) | 4600 | TYPE | Wheel edge deceleration |
| Budcket width(mm) | 600 | TYRE | |
| Bucket capacity(m3 ) | 0.2 | size | 16/70-20 |
| Max. Digging height(mm) | 4300 | Front wheel pressure(KPa) | 250 |
| Max. force(KN) | 28 | Back wheel pressure(KPa) | 250 |
| DiggingRotary angle (°) | 180 | service brake | Oil brake drum brake |
| LOADER PARAMETER | Parking brake | manual | |
| Max.unloading height(mm) | 3500 | FUEL | |
| Max. Unloading distance(mm) | 900 | Fuel tank(L) | 50 |
| Loading bucket width(mm) | 2100 | Hydraulic oil tank(L) | 50 |
| Loading bucket width(m3 ) | 1 | OTHERS | |
| Max.Loading Lifting Capacity(mm) | 4300 | Driving type | 4*4 wheel |
| Maximum rising power(KN) | 42 | Variable speed type | hydraulic transmission |
| Loading bucket working time(s) | 12 | Brake distance(mm) | 600 |
Mini Backhoe Loader With Versatile Operation HT20-28 Images
Mini Backhoe Loader With Versatile Operation HT20-28 Applications
The HT20-28 mini backhoe loader is designed for a wide range of small and medium-scale engineering projects where flexibility, efficiency, and multifunctional operation are required. In construction projects, it can be used for foundation preparation, trench digging, pipeline installation, soil excavation, and material loading, helping operators complete multiple tasks with one machine. For agricultural applications, the machine is suitable for farmland maintenance, irrigation channel construction, land leveling, and farm infrastructure projects. Its compact structure and flexible steering system also make it practical for municipal maintenance, landscaping, road repair, and other projects where working space is limited. With both excavation and loading capabilities, the HT20-28 provides a reliable solution for contractors, farmers, and operators looking for a versatile compact backhoe loader.
HIGHTOP Service Support
HIGHTOP provides complete support for HT20-28 mini backhoe loader customers, including product consultation, technical guidance, customized configurations, spare parts supply, shipping assistance, and after-sales service.
Before purchasing, our professional team helps customers select suitable equipment according to project requirements, working environment, attachment needs, and transportation conditions.
For dealers, contractors, and engineering companies, HIGHTOP supports OEM cooperation, bulk orders, and customized solutions.
After delivery, HIGHTOP provides operation guidance and maintenance recommendations to help customers keep their equipment working efficiently and reliably.
Mini Backhoe Loader Frequently Asked Questions
1. What is a mini backhoe loader used for?
A mini backhoe loader combines digging and loading functions and is commonly used for construction, agriculture, landscaping, and material handling projects.
2. What are the advantages of HT20-28 backhoe loader?
The HT20-28 provides multifunctional operation, allowing users to complete excavation and loading tasks with one machine.
3. Can HT20-28 work in small spaces?
Yes. Its compact structure and flexible steering system make it suitable for projects with limited working areas.
4. Can attachments be installed on this mini backhoe loader?
Yes. Different attachments such as buckets and drill rods can be selected according to application requirements.
5. Is HT20-28 suitable for farms?
Yes. The machine is suitable for agricultural tasks including soil handling, trenching, and land preparation.
