Small Wheel Backhoe Loader With Flexible Mobility HT08-12 Introduction
The HIGHTOP HT08-12 Small Wheel Backhoe Loader is a compact and practical construction machine designed for users who need flexible transportation, efficient operation, and multifunctional working capability. Combining front loading and rear excavation functions, this small wheel backhoe loader provides an ideal solution for small construction projects, agricultural work, municipal maintenance, and general earthmoving tasks.
Unlike traditional single-purpose equipment, the HT08-12 allows operators to complete digging, trenching, loading, and material handling operations with one machine. The front loader bucket is suitable for moving soil, gravel, and other materials, while the rear backhoe system provides reliable excavation capability for small-scale digging projects.
The machine adopts a 4×4 wheel drive system and articulated full hydraulic steering, providing excellent maneuverability and stability on different working surfaces. With a compact structure and a minimum turning radius of approximately 3000mm, the HT08-12 can operate efficiently in narrow areas where larger construction equipment may not be practical.
Powered by a reliable diesel engine and equipped with a hydraulic working system, the HT08-12 delivers stable performance for daily operations. The machine features a maximum digging depth of 1500mm and a 0.4m³ loading bucket, making it suitable for light excavation, material transportation, land preparation, and maintenance work.
The HT08-12 small wheel backhoe loader is a practical choice for contractors, farmers, and small business owners looking for a cost-effective machine that combines mobility and functionality. For customers searching for a small backhoe loader for sale, wheel backhoe loader, or compact construction equipment, HIGHTOP provides reliable machinery solutions with professional support.
Small Wheel Backhoe Loader With Flexible Mobility HT08-12 Parameters
| Model:HT08-12 | |||
| DIMENSION | ENGINE | ||
| Overall size(mm) | 5100*1350*2580 | Engine Model | Changchai 390(YUNNEI 490) |
| Wheel base(mm) | 1910 | Type | Three Stroke<span font-size:6.5pt;"="">，Four-Stroke |
| Wheel tread(mm) | 1100 | Rated Power(KW) | 25(37) |
| Min. Ground Clearance(mm) | 250 | Rated Rotary speed(r/min) | 2400 |
| PERFORMANCE PARAMETER | Cylinders - inner diameter | 3-90(4-90) | |
| Pressure of the system(MPa) | 16 | DRIVE SYSTEM | |
| Machine weight(Kg) | 2200 | Gearbox | Fixed shaft power shift |
| Max. speed(Km/h) | 20 | Optional Gears | Front 2 rear2 |
| Max Climb Capability(°) | 25 | Hydraulic torque converter | ZL28F |
| Min. turning radius(mm) | 3000 | EPS | |
| DIGGING PARAMETER | type | Articulated full hydraulic steering | |
| Max. Digging depth(mm) | 1500 | Steering angle(°) | 33 |
| Dumping Height(mm) | 1500 | BRIDGE | |
| Max. Digging Radius(mm) | 2000 | TYPE | 130 |
| Budcket width(mm) | 350 | TYRE | |
| Bucket capacity(m3 ) | 0.08 | size | 8.25-16 |
| Max. Digging height(mm) | 2600 | Front wheel pressure(KPa) | 250 |
| Max. force(KN) | 25 | Back wheel pressure(KPa) | 250 |
| DiggingRotary angle (°) | 180 | service brake | Oil brake drum brake |
| LOADER PARAMETER | Parking brake | manual | |
| Max.unloading height(mm) | 2200 | FUEL | |
| Max. Unloading distance(mm) | 800 | Fuel tank(L) | 20 |
| Loading bucket width(mm) | 1300 | Hydraulic oil tank(L) | 20 |
| Loading bucket width(m3 ) | 0.4 | OTHERS | |
| Max.Loading Lifting Capacity(mm) | 3000 | Driving type | 4*4 wheel |
| Maximum rising power(KN) | 28 | Variable speed type | hydraulic transmission |
| Loading bucket working time(s) | 12 | Brake distance(mm) | 300 |
Small Wheel Backhoe Loader With Flexible Mobility HT08-12 Images
Small Wheel Backhoe Loader With Flexible Mobility HT08-12 Applications
Small Construction Projects
The HT08-12 wheel backhoe loader is suitable for foundation preparation, small trench excavation, material loading, and site maintenance work.
It provides a practical solution for contractors who need flexible equipment for multiple daily tasks.
Agricultural Applications
The machine can be used for farmland maintenance, irrigation channel construction, soil handling, and agricultural infrastructure improvement.
Its wheeled structure allows convenient movement around farms and rural working areas.
Municipal Maintenance
The compact design makes it suitable for roadside maintenance, drainage work, pipeline preparation, and small municipal engineering projects.
Landscaping And Property Maintenance
The HT08-12 can assist with soil preparation, landscaping excavation, material movement, and ground improvement tasks.
Material Handling
The front loading bucket can efficiently handle soil, sand, gravel, and other loose materials during construction and maintenance operations.
HIGHTOP Service Support
HIGHTOP provides complete support for HT08-12 small wheel backhoe loader customers, including product consultation, equipment selection guidance, spare parts supply, transportation assistance, and technical support.
Before purchasing, our professional team helps customers choose suitable configurations according to their working environment, project requirements, and application needs.
For dealers, contractors, and agricultural users, HIGHTOP supports customized solutions, bulk purchasing, and OEM cooperation.
After delivery, HIGHTOP provides operation guidance, maintenance suggestions, and technical assistance to help customers maintain stable equipment performance and reduce operating costs.
Small Wheel Backhoe Loader Frequently Asked Questions
1. What is a small wheel backhoe loader used for?
A small wheel backhoe loader is used for digging, loading, trenching, material handling, and light earthmoving projects in construction, agriculture, and municipal applications.
2. What makes HT08-12 different from larger backhoe loaders?
The HT08-12 focuses on mobility and flexibility. Its compact size and wheeled design make it easier to transport and operate in smaller working areas.
3. Can HT08-12 work on farms?
Yes. The machine is suitable for farmland maintenance, irrigation construction, soil handling, and other agricultural tasks.
4. Does the HT08-12 use four-wheel drive?
Yes. The HT08-12 adopts a 4×4 wheel drive system to improve traction and working stability.
5. Is this machine suitable for small contractors?
Yes. The HT08-12 is designed for contractors and users who need a compact, economical, and multifunctional construction machine.
